Product Description
NKW200Q is a fully automatic horizontal baler for high-output recycling and industrial sites with strict needs. It automates feeding, compression, bundling and unloading into one smooth flow, saving labor and boosting efficiency.
Its extra-strong frame and powerful hydraulic system ensure steady, high compression. Even under non-stop use, it makes tight, uniform bales. More capable and tougher than smaller large models, it is ideal for extreme, high-volume jobs.
Video
Key Features
●Ultra-High-Capacity Automated Baling System
Built for continuous, large-volume material processing with fully automated feeding, compaction, tying, and bale discharge.
●Maximum Compression Power for Industrial Applications
Delivers extreme baling force to compact heavy, bulky, and high-density recyclable materials efficiently.
●Extra-Heavy-Duty Structural Design
Industrial-grade steel construction engineered to withstand constant high loads and long-term intensive operation.
●High-Performance Hydraulic Drive with Heat Management
Advanced hydraulic system combined with fan-assisted cooling ensures stable pressure output during extended, high-intensity working conditions.
●High-Density, Uniform Bale Formation
Produces tightly compressed, consistently shaped bales that optimize storage efficiency and reduce transportation costs.
NKW200Q Specification
|
Name |
parameter |
|
Bale size |
1100mm（W）×1100mm（H）×～1800mm(L) |
|
Material type |
Scrap Kraft paper, Newspaper, Cardboard, Film, |
|
Material density |
650～750Kg/m3（Moistures 12-18%） |
|
Feed opening size |
2400mm×1100mm |
|
Main motor power |
37KW×2sets+15KW |
|
Main cylinder |
YG300/230-2900 |
|
Main cylinder force |
200T |
|
Capacity |
28-30Ton/hour |
|
Max. Pressure |
30.5MPa |
|
Mainframe weight(T) |
About 34 tons |
|
Oil tank |
2m3 |
|
Mainframe size |
About 11×4.3×5.8M（L×W×H） |
|
Tie wire line |
4 line φ3.0-3.2mm3 iron wire |
|
Pressure time |
≤30S/ (go and back for empty load) |
|
Conveyor weight |
About 7 tons |
|
Conveyor size |
2000*14000MM |
|
terra hole size |
7.303M（L）×3.3M（W）×1.2M（deep） |
|
Conveyor motor |
7.5KW |
|
Cool tower motor |
0.75KW（water Pump）+0.25（Fan） |
Why Choose NKW200Q
NKW200Q is designed for customers who require a large-capacity, fully automatic baling solution capable of handling extreme workloads. With its powerful compression, robust construction, and reliable automation, the NKW200Q helps large operations achieve maximum efficiency, stable output, and lower long-term operating costs.
