Product Description
NKW160Q is a fully automatic horizontal baler made for large recycling facilities and industrial sites with high material volumes. It combines automated feeding, compression, strapping and bale ejection into a non-stop workflow, cutting labor needs a lot and boosting productivity.
With an extra-heavy-duty frame and a high-power hydraulic system, it provides strong, steady compression force. It makes uniform, high-density bales even during long work cycles, and its tough build ensures long use and reliable performance in tough industrial environments.
Video
Key Features
●Automated Continuous Baling System
Designed for uninterrupted operation, integrating automatic material intake, compaction, tying, and bale discharge in one continuous process.
●Large-Capacity Processing Capability
Optimized for facilities handling high and continuous waste output, improving overall processing efficiency.
●Reinforced Heavy-Duty Frame Construction
Extra-strength steel structure enhances machine rigidity and ensures long-term durability under heavy workloads.
●Advanced Hydraulic Drive with Thermal Stability
High-efficiency hydraulic system designed to maintain stable pressure and smooth operation during extended running hours.
●Fan-Assisted Cooling System
Integrated cooling fans support effective heat dissipation, helping maintain optimal operating temperatures during high-intensity continuous operation.
●Service-Friendly Design for Long-Term Operation
Optimized layout and quality components simplify maintenance and support long service life.
NKW160Q Specification
|
Name |
Parameter |
|
Bale size |
1100mm（W）×1100mm（H）×～1600mm(L) |
|
Material type |
MSW Waste |
|
Material density |
400～600Kg/m3（Moisture12-15%） |
|
Feed opening size |
2000mm×1100mm |
|
Output |
10-12 tons/hour |
|
Main motor power |
45KW+11kw |
|
Main cylinder |
YG280/210-2700 |
|
Main cylinder force |
160T |
|
Max Pressure |
25MPa |
|
Mainframe weight(T) |
About 28 tons |
|
Mainframe size |
About 11×2.3×2.9M（L×W×H） |
|
Tie wire line |
5 line φ2.75～φ3.0mm3 iron wire |
|
Pressure time |
22≤S/ (go and back) |
|
Conveyor weight |
About 5 tons |
|
Conveyor size |
2000*14000MM |
|
Conveyor motor |
7.5KW |
|
Cool motor |
0.75KW Fan cooling |
|
Heating system |
5.5kw water heating system |
Why Choose NKW160Q
NKW160Q is designed for customers who require a large-capacity, fully automatic baling solution capable of handling intensive workloads. With its heavy-duty construction, high compression force, and reliable automation, the NKW160Q helps large operations achieve maximum efficiency, lower operating costs, and consistent recycling performance.
