Product Description
NKW160QT is a horizontal baler with an automatic tying system and a lifting door design, built for handling large volumes in industrial and recycling settings. The automatic tying ensures secure bales, reducing manual labor and boosting efficiency.
The lifting door allows easy feeding of bulky materials and smooth bale discharge. With a heavy-duty frame and high-power hydraulic system, the NKW160QT delivers strong, stable compression, producing uniform, high-density bales during long operations.
Video
Key Features
●Automatic Wire Tying System
Provides fast and secure bale tying with stable performance and low maintenance.
●Lifting Door Feeding Design
Improves material loading efficiency and supports smooth bale discharge.
●High Compression Force for Large Volumes
Designed to handle high material throughput with strong and stable compression.
●Heavy-Duty Steel Structure
Reinforced frame ensures durability and reliable operation under continuous heavy loads.
●Stable Hydraulic System
Delivers consistent pressure output for uniform bale density during long working hours.
NKW160QT Specification
|
Name |
parameter |
|
Bale size |
1100mm（W）×1250mm（H）×～1600mm(L) |
|
Material type |
Cardboard ,Soft Film, PET Bottle |
|
Material density |
500～600Kg/m3(Mositure12-18%） |
|
Feed opening size |
2000mm×1100mm |
|
Main motor power |
45KW+7.5kw |
|
Main cylinder |
YG280/210-4500 |
|
Capacity |
12-15ton /hour |
|
Main cylinder force |
160T |
|
Max. Pressure |
30.5MPa |
|
Mainframe weight(T) |
About 28 tons |
|
Oil tank |
2m3 |
|
Mainframe size |
About 13×4.3×5.8M（L×W×H） |
|
Tie wire line |
5 line φ3.0～φ3.2mm3 iron wire |
|
Pressure time |
≤35S/ (go and back for empty load) |
|
Conveyor weight |
About 5 tons |
|
Conveyor size |
2000*12000MM |
|
Conveyor motor |
4KW |
|
Cool tower motor |
0.75KW（water Pump）+0.25（Fan） |
Why Choose NKW160QT
NKW160QT is ideal for users who need automatic tying, flexible feeding, and higher processing capacity. Its lifting door design, strong compression performance, and durable structure make it a reliable solution for large-scale recycling and industrial waste management operations.
