Product Description
NKW180Q is a fully automatic horizontal baler made for high-output recycling facilities and industrial operations. It brings together automated feeding, compression, bundling and bale unloading into a smooth, non-stop process—cutting down manual work and ramping up productivity.
Equipped with a heavy-duty frame and high-power hydraulic system, this baler delivers strong, steady compression force. It turns out uniform, high-density bales even during long hours of operation. Better than other large but smaller-sized models, it has higher processing capacity and longer service life, perfect for non-stop, heavy-load tasks.
Video
Key Features
●High-Capacity Fully Automated Baling Process
Designed for uninterrupted operation, enabling continuous material feeding, compaction, tying, and bale discharge with minimal human involvement.
●Extreme Compression Performance for Large Volumes
Provides powerful baling force to efficiently compress bulky and high-volume recyclable materials into dense, stable bales.
●Heavy-Duty Industrial Structure
Extra-strength steel construction ensures structural stability and reliable performance under constant high-load and long-hour operation.
●Advanced Hydraulic System with Thermal Control
High-efficiency hydraulic configuration combined with fan-assisted cooling supports stable pressure output during extended, high-intensity operation.
●Consistent, Transport-Optimized Bale Output
Produces uniform, high-density bales that reduce storage space requirements and improve logistics and transportation efficiency.
NKW180Q Specification
|
Name |
parameter |
|
Bale size |
1100mm（W）×1100mm（H）×～1600mm(L) |
|
Material type |
Plastic ,Industrial waste, Newspaper, Cardboard , |
|
Material density |
500～600Kg/m3（Moisture 12-18%） |
|
Feed opening size |
2400mm×1100mm |
|
Main motor power |
37.5KW*2set+15kw |
|
Main cylinder |
YG300/230-2900 |
|
Main cylinder force |
180T |
|
Capacity |
22-25T/H |
|
Max. Pressure |
30.5MPa |
|
Mainframe weight(T) |
About 32Tons |
|
Oil tank |
2m3 |
|
Mainframe size |
About 11×4.3×5.8M（L×W×H） |
|
Tie wire line |
5 line φ2.75～φ3.0mm3 iron wire |
|
Pressure time |
≤22S/ (go and back for empty load) |
|
Conveyor weight |
About 8 tons |
|
Conveyor size |
2000*16000MM |
|
terra hole size |
7.303M（L）×3.3M（W）×1.2M（deep） |
|
Conveyor motor |
11KW |
|
Cool tower motor |
0.75KW（water Pump）+0.25（Fan） |
Why Choose NKW180Q
NKW180Q is an ideal solution for customers who require higher capacity and stronger compression than standard large balers. Designed for continuous, heavy-duty operation, it helps large-scale facilities improve productivity, optimize waste handling, and reduce overall operating costs.
