Product Description
NKW80Q is a fully automatic horizontal baler engineered for facilities with growing material volumes and continuous operation needs. It combines automatic feeding, compression, tying, and bale discharge into a seamless process, cutting down manual labor significantly and improving overall efficiency.
Equipped with a reinforced frame and optimized hydraulic system, the NKW80Q delivers stable compression force and evenly dense bales. Outperforming smaller models in throughput and durability, it is perfectly suited for medium-sized recycling centers and industrial applications where reliability and performance are non-negotiable.
Video
Key Features
●Fully Automatic Operation
Automatic feeding, compressing, tying, and bale discharging enable continuous and efficient processing with minimal labor input.
●Powerful & Stable Hydraulic System
High-performance hydraulic components provide strong and consistent compression force, ensuring stable operation and uniform bale density.
●Improved Processing Capacity
Designed for medium-volume material handling, suitable for facilities with stable to high waste output.
●Reinforced Steel Structure
Heavy-duty frame ensures durability, stability, and long service life under continuous operation.
●Low Maintenance Design
Simple mechanical structure and high-quality components reduce downtime and maintenance costs.
NKW80Q Specification
|
Name |
parameter |
|
Bale size |
1100mm（W）×800mm（H）×～1600mm(L) |
|
Material type |
Scrap Kraft paper, Carton, Cardboard ,Soft Film |
|
Material density |
300～400Kg/m3（moistures 12-15%） |
|
Feed opening size |
1500mm×800mm |
|
Main motor power |
30KW+11kw |
|
Capacity |
3-5T/Hour |
|
Main cylinder |
YG220/160-2600 |
|
Main cylinder force |
80T |
|
Max. pressure |
21MPa |
|
Mainframe weight(T) |
About 15 tons |
|
Mainframe size |
About 9.8m×4.3m×1.4m（L×W×H） |
|
Tie wire line |
4 line φ2.75～φ3.0mm3 iron wire |
|
Pressure time |
≤30S/ (go and back) |
|
Chain Conveyor Size |
1200㎜（W）*12000㎜（L） |
|
Motor power |
4KW |
|
Control way |
Automatic / manual |
Why Choose NKW80Q
The NKW80Q is an ideal solution for customers upgrading from small-capacity balers or seeking a reliable medium-size automatic baling system. It combines increased productivity, stable automation, and industrial-grade construction, helping businesses improve waste handling efficiency and reduce operational costs over the long term.
