Product Description
The multi-functional baler with automated pressure plate control delivers a universal solution: high compaction density, full automation, and economic efficiency. It can handle up to 90% of secondary raw material baling needs on a single line, thereby saving space, resources, and time. Whether you process PET bottles or paper waste, this is no compromise — it's a next-level solution.
Video
Key Features
●Two modes in one machine
This machine adopts closed-end design for resilient materials and open-end design for soft and bulky fractions.
●Fully Automatic Compression & Baling
The system automatically compresses and bales materials, making it easier to store and transport, lowering logistics costs.
●High-Speed Automatic Strapping
A fast and simple automatic strapping system with low failure rates that’s easy to clean and maintain.
●Flexible Feeding Options
It supports both conveyor and air-blower feeding, ideal for recycling plants dealing with cardboard, plastics, textiles, or large waste disposal.
●Automatic Fault Detection
The system automatically identifies faults and displays them, reducing downtime and improving inspection.
●Simple Operation & Quick Mode Switching
Operators can finish simple operations and rapidly switch working modes to adapt to different waste materials.
NKW-QT series Specification
| Model | NKW100QT | NKW125QT | NKW160QT | NKW180QT |
| Pressure(KN) | 1000KN | 1250KN | 1600KN | 1800KN |
| Cylinder size | Φ220 | Φ250 | Φ280 | Φ300 |
| Bale size(MM)(W*H) | 1100*850mm | 1100*850mm | 1100*1100mm | 1100*1100mm |
| Bale weight(KG) | 550-750KG | 950-1100KG | 1100-1300KG | 1100-1300KG |
| Capability(T/H) | 4-6T/H | 5-8T/H | 6-8T/H | 8-10T/H |
| Material density(KG/m³) | 300-400KG/m³ | 400-450KG/m³ | 500-550KG/m³ | 550-600KG/m³ |
| Bale line | 4line | 5line | 4-5line | 5line |
| Strapping way | Automatic | Automatic | Automatic | Automatic |
| Power(KW) | 30KW | 37KW | 45KW | 45KW |
| Feeding device | conveyor | conveyor | conveyor | conveyor |
| Conveyor size(MM)(L*W) | 10000*1800mm | 12000*2000mm | 13000*2000mm | 13000*2000mm |
| Machine weight(T) | 19T | 22T | 28T | 32T |
Why Choose NKW100QT
NKW-QT series hybrid baler with automated pressure plate control is a universal solution that combines high compaction density, full automation, and economic efficiency. It can cover up to 90% of secondary raw material baling needs on a single line, saving space, resources, and time. If you process both PET and paper waste — this is not a compromise, it’s a next-level solution.
