Product Description
NKB280-2 Twin Ram Hydraulic Baler (45kW) is an enhanced version of the NKB280 series, developed for users who demand higher efficiency and faster processing speed. Equipped with a twin ram hydraulic structure, the machine applies strong and even compression to loose agricultural materials, producing dense, uniform bales suitable for storage, transport, and export.
Powered by a 45kW main motor and built with a heavy-duty steel frame, the NKB280-2 handles large volumes of straw and forage materials with ease. The increased motor power shortens the baling cycle, improves hourly capacity, and helps reduce overall labor and logistics costs.
Video
Key Features
●Twin ram hydraulic system ensures powerful and stable compression
●45kW motor provides faster baling speed and higher working efficiency
●Bale weight 450kg+, maximizing container loading and avoiding weight loss
●Uniform and compact bale shape for easy stacking and transportation
●Heavy-duty construction designed for long-term agricultural use
NKB280-2 Specification
|
Name |
parameter |
|
Bale size |
1050mm（W）×1250mm（H） |
|
Material type |
Wheat straw, Hay Alfalfa, Grass |
|
Material density |
300～400kg/m3 |
|
Feed opening size |
2600mm×1100mm |
|
Main motor power |
45kw |
|
Main cylinder |
YG350-4300 |
|
Capacity |
6-8ton /hour |
|
Main cylinder force |
280T |
|
Max. Pressure |
30MPa |
|
Mainframe weight(T) |
About 24 tons |
|
Oil tank |
1600L |
|
Mainframe size |
About 9.8×1.6×1.9M（L×W×H） |
|
Bale Wire Line |
Manual tie with bags |
|
Control And Out-bale Way |
PLC Automatic Control, Push Bag |
|
Conveyor weight |
About 5 tons |
|
Conveyor size |
2000*12000MM |
|
Conveyor motor |
4KW |
|
Cool tower motor |
0.75KW（water Pump）+0.25（Fan） |
Why Choose NKB280-2
NKB280-2 (45kW) is the ideal choice for customers who need higher output without moving to oversized equipment. Compared with the 37kW model, it offers faster baling cycles, improved hourly capacity, and greater overall efficiency—while still delivering 450kg+ bale weight to ensure full container loading and lower transportation costs.
