NKB5 Used Rag Baler Machine

NKB5 Used Rag Balers is used for compressing small and soft material, such as clothing, fabric, sawdust, fertilizer, feed stuff, etc,then pack the material into handy and small bags this used rag baler machine is ideal for volume reduction of wood shavings,rice husks.used rags ,textiles ,and so on loose materails,its feeding by manual or conveyor both ok.

product details

specification

Why Choose NKB5

Product Description

NKB5 Used Rag Baler Machine is engineered to compress loose used rags and wiping cloths using stable hydraulic pressure, transforming scattered and bulky rags into dense, uniform bales. This dedicated design ensures that used rags are consistently compressed without damaging the material, making the baler ideal for rag recycling and cleaning cloth packaging applications.

During operation, used rags are fed into the chamber and compressed in one continuous process, allowing used rag compression, baling, and ejecting to be completed with minimal manual intervention. The evenly compressed wiping cloth bales are easy to stack, store, and transport, significantly improving handling efficiency and warehouse organization.

Video

Key Features

●Specialized for Used Rag CompressionSpecialized for Used Rag Compression
Designed specifically to compress used rags and wiping cloths without damaging fiber structure.

●Uniform Bale WeightUniform Bale Weight
Equipped with a weighing device to ensure consistent bale weight of compressed rags.

●One-Button OperationOne-Button Operation
Only one press button is required to complete used rag compressing, baling, and ejecting, making operation simple and labor-saving.

●One-Time FeedingOne-Time Feeding
Loose used rags can be fed at one time, improving rag compression efficiency and reducing manual handling.

●Integrated Compression & BaggingIntegrated Compression & Bagging
Combines used rag compression and bagging into one process—simply place the plastic bag on the outlet and the machine completes the compression automatically.

NKB5 Specification

Name	parameter
Bale Size	400300100mm
Bale Weight	5kg
Motor Power	7.5KW/10HP
Output Capacity	80 bales/h
Voltage	380V/50HZ
Machine Size	260017501480mm
Machine Weight	1100kg
Main Cylinder	Pressure	100KN	Stroke	950mm
Push Out Cylinder	Pressure	125KN	Stroke	530mm
Steel Plate Thickness	12mm		Q345B
Pump	HengYuan		China Brand
	Flow		63Ml/R
Valve	Yuken
O Ring	NOK		Japan
Working Pressure	15PMA
Oil Tank	200l		#46/#68
Motor	Siemens		Germany
Electrical Components	Delixi		China Brand

Why Choose NKB5

NKB5 Used Rag Baler Machine is an ideal choice for customers who need a simple, reliable, and efficient solution for compressing used rags and wiping cloths. Its compact structure, stable compression performance, and user-friendly operation help businesses reduce storage space, lower logistics costs, and improve the overall efficiency of used rag recycling and packaging operations.
