Product Description
NKB280-1 Briquette Press Machine for Biomass is engineered to deliver consistent, high-quality cylindrical briquettes from a wide range of agricultural and forestry residues. Featuring a heavy-duty hydraulic system paired with a precision-engineered forming die, this machine ensures that each briquette maintains uniform diameter and structural integrity—critical for downstream applications such as industrial combustion, gasification, or commercial heating.
The feed hopper is designed with an anti-bridge mechanism to handle fibrous materials like straw, corn stalks, and wood shavings without clogging, while the automated lubrication system extends the life of key wear parts, reducing maintenance downtime. Operators benefit from a user-friendly control panel that allows real-time adjustment of compression parameters, ensuring optimal density regardless of feedstock moisture variation.
Video
Key Features
●Twin ram hydraulic system for stable and uniform compression
●37kW motor suitable for standard straw baling operations
●Bale weight 450kg+, maximizing container loading efficiency
●Compact bale shape, easy to stack and transport
●Heavy-duty structure designed for agricultural environments
NKB280-1 Specification
|
Name |
parameter |
|
Bale size |
1050mm（W）×1250mm（H） |
|
Material type |
Wheat straw, Hay Alfalfa, Grass |
|
Material density |
300～400kg/m3 |
|
Feed opening size |
2600mm×1100mm |
|
Main motor power |
37kw |
|
Main cylinder |
YG350-4300 |
|
Capacity |
4-6ton /hour |
|
Main cylinder force |
280T |
|
Max. Pressure |
30MPa |
|
Mainframe weight(T) |
About 24 tons |
|
Oil tank |
1600L |
|
Mainframe size |
About 9.8×1.6×1.9M（L×W×H） |
|
Bale Wire Line |
Manual tie with bags |
|
Control And Out-bale Way |
PLC Automatic Control, Push Bag |
|
Conveyor weight |
About 5 tons |
|
Conveyor size |
2000*12000MM |
|
Conveyor motor |
4KW |
|
Cool tower motor |
0.75KW（water Pump）+0.25（Fan） |
Why Choose NKB280-1
Choosing the NKB280-1 Briquette Press Machine for Biomass means investing in a solution that delivers consistent quality, operational stability, and long-term value. Unlike many conventional presses that struggle with feedstock variations, this machine is engineered to maintain stable briquette density even when processing materials with fluctuating moisture levels or inconsistent particle sizes—a common challenge in real-world biomass operations. Its robust construction minimizes wear and tear, reducing unplanned downtime and keeping maintenance costs predictable.
