Machine Weight: | Customizable | Bale Density: | 500-600kg/m3 |
---|---|---|---|
Safety Features: | Emergency Stop Button, Safety Door, Overload Protection | Machine Price: | Good |
Type: | Horizontal Baler | Bear: | NSK |
Bale Size: | 1100mm X 1100mm X 1200mm | Model: | NKW180Q |
Bale Tying: | Automatic Wire Tying | Capacity: | 10-15 Tons Per Hour |
Seals: | America | Quality: | Good |
Color: | Green | Application: | Waste Management, Recycling |
Steel: | Bao Steel |
A scrap briquetting machine is a mechanical device used to compress metal or non-metal scrap into blocks for recycling or to reduce storage space. Such machines are typically used in scrap recycling depots, factories, smelters, and scrap processing centers to process iron filings, aluminum filings, copper filings, plastic fragments, and other industrial waste.
Item | Name | parameter |
mainframe parameter |
Bale size | 1100mm(W)×1100mm(H)×~1600mm(L) |
Material type | Scrap Kraft paper, Carton, Cardboard ,Soft Film | |
Material density | 400~500Kg/m3(moisture 12-15%) | |
Feed opening size | 1800mm×1000mm | |
Output | 7-9tons/hour | |
Main motor power | 37.5KW+11 KW | |
Main cylinder | YG220/160-2600 | |
Main cylinder force | 100T | |
Max. system working force | 21MPa | |
Mainframe weight(T) | About 19 tons | |
Mainframe size | About 11×2.3×2.9M(L×W×H) | |
Tie wire line | 4 line φ2.75~φ3.0mm3 iron wire | |
Pressure time | ≤30S/ (go and back) | |
conveyor technology Chain | Model | NK-II |
Conveyor weight | About 5 tons | |
Conveyor size | 2000*12000MM | |
terra hole size | 7.303M(L)×3.3M(W)×1.2M(deep) | |
Conveyor motor | 5.5KW | |
Cooling system | Water tank | 6M3 |
Motor | 0.75kw |
The main features of the scrap briquetting machine include:
1. High-pressure compression: The high pressure generated by the hydraulic system is used to compress the waste materials into blocks, which greatly reduces the volume of the waste materials and facilitates transportation and storage.
2. Automated operation: Modern scrap briquetting machines are usually equipped with automatic control systems, which can automate the compression cycle and improve production efficiency.
3. Safety: For the safety of operators, scrap briquetting machines are usually equipped with safety devices such as safety valves and emergency stop buttons.
4. Sturdy structure: Due to the need to withstand high pressure, the body of the scrap briquetting machine is usually made of high-strength steel to ensure the durability of the equipment.
5. Versatility: Some waste briquetting machines are designed to be multi-purpose and can handle different types of waste to accommodate a variety of industrial needs.
The use of waste briquetting machines not only contributes to the recycling and reuse of waste, but is also of great significance to environmental protection and resource conservation. By compressing waste, companies can reduce waste disposal costs while also serving as an environmental measure to reduce reliance on landfills.
